New sea spider found in Norwegian waters

The sea spider Cilunculus battenae was recently recorded in the Norwegian Economic Zone (NEZ) for the first time, when bottom samples from the MAREANO cruises from 2007-2009 were analysed. So far 21 different species have been found in the samples. Two species have previously been observed in the NEZ a few times.

The sea spider Cilunculus battenae was recently recorded in the Norwegian Economic Zone (NEZ) for the first time, when bottom samples from the MAREANO cruises from 2007-2009 were analysed. So far 21 different species have been found in the samples. Two species have previously been observed in the NEZ a few times.

By Beate Hoddevik Sunnset

Cilunculus battenae
The sea spider
Cilunculus battenae (photo: Arne Hassel, IMR).

Cilunculus battenae was found at 388 m depth off northern Norway. It has previously been observed further south, at the Wyville-Thompson ridge (between the Faroe Islands and Shetland) and at the Cape Verde slope (West Africa), from  690 - 1160 m depth. The discovery in the NEZ is the northernmost observation of the species. It was first described as late as 1993, possibly because it is a small species easy to overlook.

- We know relatively little about sea spiders, particularly species from the deep oceans. We are therefore focusing on studying the species composition and the geographic distribution of sea spiders found in the MAREANO material,  Arne Hassel,  researcher at The Institute of Marine Research, and Halldis Ringvold,  Marine Biologist at Akvaplan-Niva as, explain.

Sea spiders

There is some disagreement as to how sea spiders should be classified, but for a long time they have been considered arthropods in the class Pycnogonida. They have relatively long legs and small bodies. Unlike spiders that live on land, some of the sea spiders internal organs (such as the digestive tract and reproductive organs) are placed in the legs. Sea spiders are marine animals found in all oceans, and at both poles. Pycnogonida means “with many knees”, and refers to the many leg segments.  Sea spiders have four pairs of legs for walking, and their leg span and body length vary greatly. A medium-sized sea spider may have a leg span of 5-7 cm, and large    species, can have leg spans of up to 70 cm. The leg span of the largest species found in Norway can reach 25 cm.

Further investigations

- In collaboration with a British expert on sea spiders we have now finished identifying species found, the scientists explain.

They are now going to relate the distribution of sea spiders to environmental conditions such as temperature, depth and sediment.

- We also aim to use nature types in order to describe the pycnogonid habitat preferences, the two scientists explain.


More about sea spiders:

By Arne Hassel and  Halldis Ringvold

There is some disagreement as to how sea spiders should be classified, but for a long time they have been considered arthropods. They are marine animals, and are found in all of the oceans and at both poles. Pycnogonida means “with many knees”, and refers to the many segments that make up the legs.

Sea spiders have four pairs of legs for walking, and their leg spans and body lengths vary greatly. A medium-sized sea spider may have a leg span of 5-7 cm, while the very largest species, such as the Colossendeis colossea, can have leg spans of 70 cm. The species are classified on the basis of characteristics such as their claws (chelifores), their proboscis (an elongated appendage with a mouth at the end of it) and their antennae (palps) (Figure 1). For example, some species have claws and antennae, whereas others don’t. Another characteristic trait of the sea spiders is their egg-carrying (ovigerous) legs. These are used by males to carry the eggs until they hatch. Even after hatching, juveniles sometimes remain close to the male until they are quite well developed.

Figure 1
Figure 1. Examples of four types of claws (left): the large claw of the Boreonymphon (top left); the compact claws with teeth of the Pseudopallene (top right); the narrow claw of the Nymphon elegans (bottom left); and the highly vestigial claw (note scale) of the Ascorhynchus abyssi (bottom right). The large photo (right) shows an example of a sea spider without claws or antennae: Pycnogonum litorale (photo: Arne Hassel, IMR).

On the front segment of their bodies, sea spiders have a protuberance (tubercle) with a few small eyes on top of it. The shape of this protuberance is often used to help determine the species (Figure 2). In some species the tubercle and eye is greatly reduced; this is typically true of species that live in the deep oceans.

Figure 2
Figure 2. The tubercles of sea spiders vary quite a lot: on the left is the prominent tubercle of the Colossendeis; in the middle there are two “typical” Nymphon tubercles, which have conspicuous eyes with red lenses; and on the right you can see the tubercle of the blind Ascorhynchus abyssi (photo: Arne Hassel, IMR).

Sea spiders are benthic animals, and can be found from the coastal zone down to very deep waters. Some species can also display pelagic behaviour. Sea spiders move slowly, so they feed on stationary or slow-moving animals. They eat anything from sea nettles, sponges and snails, to bristle worms and algae. Approximately 40 species of sea spider have previously been identified in Norwegian coastal waters. The MAREANO programme, which is also collecting species from the deep oceans, has so far found 21 species (May 2011). The map (Figure 3) shows where the species discussed below were found.

Figure 3
Figure 3. Locations of the stations mentioned in the article (photo: Kjell Bakkeplass, IMR).

The Cilunculus battenae (Figure 4) was found at a depth of 388 m at one station (R421). This single specimen is the first of its kind to be found in the Norwegian economic zone. The species has previously been observed further south, on the Wyville-Thomson ridge (between the Faroe Islands and Shetland) and on the Cape Verde slope (West Africa), at depths of 690-1160 m. It was first described as recently as 1993, possibly because it is a small species that is easy to overlook: it’s body is only 1.5 mm long. Its claws are quite small, almost rudimentary (vestigial).

Figure 4
Figure 4. Details of the Cilunculus battenae: rudimentary claws (chelifores), characteristic cement gland for egg sacs on leg, and claw of walking leg (photo: Arne Hassel, IMR).

The Colossendeis proboscidea and C. angusta (Figure 5) are both large species, with the former having a leg span of up to 25 cm. The C. proboscidea has a relatively long proboscis, and its legs are close together near the body, which is how it can mostly easily be distinguished from C. angusta. The two species were found at seven and five stations respectively, with no more than three individuals at any given station. C. proboscidea is considered a northern species, and in the past it has been observed off eastern Finnmark. C. angusta has a wide geographical distribution, and is considered a bipolar species. It has been identified in the Atlantic, Pacific, Arctic and Indian oceans at depths of 150 to 5000 m. In the Arctic, where even the shallow waters are cold, it has been observed at depths of 12-18 m.

Figure 5
Figure 5. Middle: the largest species in Norwegian waters, the Colossendeis proboscidea, with a proboscis longer than its body. Inset left: picture of the jaws at the end of the proboscis. Right: the closely related C. angusta, with a narrower proboscis that tapers at the front end (photo: Arne Hassel, IMR).

The Boreonymphon abyssorum, B. ossiansarsi and B. robustum (Figure 6) are spectacular, medium-sized sea spiders. Although they were mainly found at depths of 1,000-2,000 m, they were also observed in waters as shallow as 140 m. The most characteristic trait of these species is their large, curved claws. B. abyssorum is the most common Boreonymphon species in Arctic waters, and it was found at the largest number of stations in the material analysed after the MAREANO expeditions in 2007-2009. B. ossiansarsi and B. robustum were only found at one station each: R311 and R346 respectively.

Figure 6
Figure 6. The Boreonymphon genus was found relatively often, and B. abyssorum was the most common species. At station R311 we found the rarer B. ossiansarsi (pictured), but there are only small differences between the two species. The ruler on the right shows that this is a big specimen (photo: Arne Hassel, IMR).

50 individuals of the species Nymphon elegans (Figure 7) were recorded at R189 at a depth of approximately 900 m. The species has only once previously been reported in Norwegian coastal waters, in the Barents Sea near eastern Finnmark. In addition, it has been found in deeper waters in the Norwegian Sea by the researcher G. O. Sars, in the eastern part of the Icelandic economic zone, in the Kara Sea, and just north of the Wyville-Thomson ridge. The N. elegans is a slender species, with long, narrow toothed claws. It can be distinguished from other species by the fact that one of the fingers of the claw is club-shaped, rather than pointed (Figure 1).

Figure 7
Figure 7. The Nymphon elegans is a slender, smooth, medium-sized species that can easily be confused with several other Nymphon species, such as the N. macrum. Scale: 1 mm (photo: Arne Hassel, IMR).

The Ascorhynchus abyssi (Figure 8) was described by G. O. Sars in 1877 in conjunction with the Norwegian expedition to the Arctic in 1876-1879. It belongs to the deep-water family Ascorhynchidae, and has previously been found at depths of 1500-4000 m in the north-east Atlantic and in the Arctic. The species was found at two MAREANO stations (R487 and R488), at depths of 2,555 m and 2,117 m, where it was the dominant sea spider species. Both of the stations are situated in cold waters (below 0 °C), north-west of the Lofoten Islands. The Ascorhynchus abyssi is equipped with a large, downward-pointing proboscis. On its back, it has prominent protuberances on each segment. The protuberance on the front segment is a tubercle, but this species does not have any eyes (Figure 2), which can be explained by the fact that it lives in constant darkness in the deep oceans. The claws are also vestigial (Figure 1).

Figure 8
Figure 8. The Ascorhynchus abyssi, which is a deep-water species, was only found at two stations during our expedition in autumn 2009. The photo on the right shows an individual with eggs. The scale at the bottom of the photo is equivalent to 1 mm (photo: Arne Hassel, IMR).

It is possible to distinguish between the Pseudopallene brevicollis and P. longicollis (Figure 9) by the different lengths of their “necks”. P. longicollis has an unusually long neck, whereas P. brevicollis has a short one. Apart from that, both species have compact, almost spherical claws with ganglia on the inside (Figure 1). A small number of Pseudopallene brevicollis individuals were found at four stations (R189, R346, R379, R416). One individual was previously reported along the Norwegian coast by G. O. Sars at the end of the 19th century, off the coast of eastern Finnmark. P. brevicollis is an Arctic species. It has previously been observed in the Kara Sea and Norwegian Sea.

Figure 9
Figure 9. Pseudopallene brevicollis, left, and P. longicollis, right. The photos show the marked difference in neck length. One of the individuals is carrying eggs (photo: Arne Hassel, IMR).
